The global manufacturing ecosystem is witnessing an unprecedented transition toward automation, precision engineering, and hyper-lean operations. In modern manufacturing, molds and dies are among the most valuable capital assets. High-precision tooling for automotive stamping, plastic injection molding, and metal die casting represents significant R&D and production capital. Safeguarding these assets while optimizing access speeds is the primary reason why advanced heavy-duty mold racks have evolved from static shelves into sophisticated mechanical structures.
Over the last decade, key shifts in industrial engineering have rewritten the requirements for mold storage:
By integrating structural carbon steel manufacturing, automated robotic welding, and localized testing standards, leading Chinese exporters deliver high-load structural reliability that conforms to European FEM standards and US RMI guidelines at highly competitive structural pricing.
Max Layer Capacity
Safety Factor Applied
Structural Steel Q235B/Q355B
Countries Exported To
Nanjing Ciho Racks Co., Ltd. is a professional manufacturer and supplier specializing in warehouse storage systems and industrial racking solutions. With years of experience in the material handling industry, we are committed to providing efficient, durable, and cost-effective storage solutions for customers worldwide.
Our product range includes selective pallet racks, drive-in racks, cantilever racks, mezzanine systems, longspan shelving, steel platforms, carton flow racks, and customized warehouse storage solutions. Designed for maximum space utilization and operational efficiency, our products are widely used in logistics centers, manufacturing facilities, distribution warehouses, e-commerce fulfillment centers, and retail storage applications.
At Ciho Racks, quality is our top priority. From product design and raw material selection to manufacturing and final inspection, every step is carried out under strict quality control standards to ensure reliability, safety, and long service life. Our experienced engineering team works closely with customers to develop tailored storage solutions that meet specific warehouse requirements.
Driven by innovation, customer satisfaction, and continuous improvement, we have established long-term partnerships with clients across Europe, North America, Southeast Asia, the Middle East, and many other regions.
Nanjing Ciho Racks Co., Ltd. is dedicated to delivering high-quality products, competitive pricing, on-time delivery, and professional technical support. We look forward to becoming your trusted partner for warehouse storage and logistics solutions.
Dedicated production lines for industrial heavy-duty racking systems, custom configured to match localized industrial footprints.
Automated CNC punching, cold roll-forming lines, and robotic welding stations guarantee precise structural tolerances and load safety.
Comprehensive export experience, ocean-compliant packaging, and responsive global technical support teams.
To optimize warehouse space and improve logistics efficiency by providing innovative, safe, and reliable storage solutions for customers around the world.
Storage configurations designed for massive body panel dies. Features custom heavy-duty structural frames, reinforced uprights, and safety lock pins to prevent dynamic roll-out under loads exceeding 5,000 kg per shelf.
Optimized for cleanrooms and automated retrieval setups. Smooth bearing drawer designs enable quick changeovers (SMED), supporting high-precision micro-cavity injection molds with low impact forces.
Specialized long-span, open-front cantilever configurations to handle oversized composite molds. Designed with dual structural bracing systems to ensure zero longitudinal flexing under uneven loads.
Industrial mold and die storage is not just a layout issue; it is a structural engineering requirement. Standard pallet racking systems are built for uniformly distributed loads (UDL). In contrast, mold racks must handle highly concentrated, localized weight profiles. When a 3-ton mold sits on a steel shelf, the load concentrated on the contact points is extreme, requiring thick structural steel plate surfaces rather than wire decking.
The next phase of industrial storage integration features automated storage and retrieval systems (AS/RS) linked with IoT weight sensors. Automated crane systems can pick and place molds from high-density slots, eliminating forklifts and crane-operator errors.
Sourcing large-scale racking systems requires strict compliance with localized structural standards. Nanjing Ciho Racks ensures all systems are engineered to pass site audits and national workplace safety inspections.
Our designs meet the specifications of the Rack Manufacturers Institute (RMI) for the design, testing, and utilization of industrial steel storage racks, a requirement for US B2B facilities.
We build our heavy-duty solutions to conform with European Federation of Materials Handling (FEM) standards, with specific attention paid to seismic bracing and structural tolerances.
We provide full layout drawings, FEA calculations, and structural calculation documents to assist local engineers in obtaining building permits and warehouse operation approvals.
Standard slider/drawer-type racks support between 1,000 kg and 3,000 kg per level. Heavy-duty configurations, constructed from heavy structural steel channels, can support up to 5,000 kg (5 tons) or 10,000 kg (10 tons) per shelf, depending on the layout and configuration.
Safety is achieved through a combination of Q355B structural steel, mechanical interlock pins that prevent more than one drawer from opening at a time (preventing tipping), structural back-bracing, and base-plates anchored with heavy expansions bolts to a minimum 150mm concrete slab.
Yes. Nanjing Ciho Racks operates a full-service in-house engineering and CAD department. We calculate frame and shelf thicknesses based on your specific mold dimensions, height limits, lifting cranes, and floor load capacities.
All upright columns and heavy beams are packed using protective bubble wraps, dynamic tension straps, and industrial wooden pallets. Small accessories are packed in reinforced wooden crates to prevent damage during sea transport.
Our standard treatment is a multi-stage electrostatic powder coating. For cleanrooms, battery manufacturing, or high-humidity environments, we offer hot-dip galvanized steel finishes for long-lasting corrosion protection.
